95% Purity Steel PSA Nitrogen Making Machine customized Color

PSA Nitrogen Generator , Which Has Advanced Process And Using Simple Method To Produce Nitrogen

Working Principle Description:

Nitrogen making equipment (nitrogen making machine) is based on pressure swing adsorption technology (PSA) and uses high-quality carbon molecular sieve as adsorbent to directly separate oxygen from compressed air and extract nitrogen. Under the pressure of purified and dried compressed air, the diffusion adsorption rate of oxygen in carbon molecular sieve micropores is much higher than that of nitrogen in carbon molecular sieve micropores. When the adsorption does not reach equilibrium, nitrogen is enriched in the gas phase to form finished nitrogen.

Then, after decompression to atmospheric pressure, the adsorbent desorbs the adsorbed oxygen and other impurities to realize regeneration. Two adsorption towers are set in the system. One tower adsorbs nitrogen and the other tower desorbs and regenerates. The PLC program controller controls the opening and closing of the pneumatic valve to make the two towers work alternately and realize the continuous production of high-quality nitrogen.

Product Advantages:

●Low cost: PSA advanced process is a simple nitrogen production method. Nitrogen is produced a few minutes after startup, with low energy consumption. The cost of nitrogen is lower than that of cryogenic air separation.

●High quality imported carbon molecular sieve: with large adsorption capacity, high compressive performance and long service life.

● High quality control valve: high quality imported special pipeline pneumatic valve can ensure the stable and reliable operation of nitrogen production equipment. Strong technical force and high-quality after-sales service. The equipment is boxed, and only the air source, power supply and water source need to be connected when it is packed on site.

Application fields:

PSA Nitrogen generator is a set of equipment that can extract nitrogen. Its main application fields are: aerospace, nuclear power, food and medicine, petrochemical industry, electronic industry, material industry, national defense and military industry and scientific experiments, such as:

Special nitrogen generator for oil and natural gas industry ---- it is suitable for nitrogen protection, transportation, coverage, replacement, rescue, maintenance, nitrogen injection and oil production in continental oil and natural gas exploitation, coastal and deep-sea oil and natural gas exploitation. It has the characteristics of high safety, strong adaptability and continuous production.

Special nitrogen generator for chemical industry ---- it is applicable to petrochemical industry, coal chemical industry, salt chemical industry, natural gas chemical industry, fine chemical industry, new materials and their derivative chemical product processing industry. Nitrogen is mainly used in covering, purging, replacement, cleaning, pressure transportation, chemical reaction stirring, chemical fiber production protection, nitrogen filling protection and other fields.

Technical parameters:

● Nitrogen delivery ≤800Nm3/hr;

● Purity 95%

● Pressure 0.5~0.8 Mpa

● Atmospheric dew point ≤－40℃

Product picture:
