Product Details:
|
| Material: | Steel | Color: | Bright Or Customized |
|---|---|---|---|
| Nitrogen Output: | ≤500 Nm3/hr | Purity: | 99.999% |
| Pressure: | 0.5Mpa | Atmospheric Dew Point: | ≤－40℃ |
| Highlight: | Steel Nitrogen PSA Unit,PSA Nitrogen Generator 0.5 Mpa,500 Nm3/hr PSA Nitrogen Plant |
||
PSA Nitrogen Generator With Stable And Reliable Nitrogen Purity And Flow
| Product name | PSA Nitrogen Generator |
| Nitrogen delivery | ≤500Nm3/hr |
| Purity | 99.999% |
| Pressure | 0.5 Mpa |
| Atmospheric dew point | ≤－40℃ |
Working Principle Description:
Pressure swing adsorption (PSA) nitrogen generator is a safe, convenient and energy-saving method for directly producing nitrogen on site. The compressed air contains 79% nitrogen, which is not only the raw material for nitrogen generation, but also the energy source for the nitrogen generator to produce 99.999% high-purity nitrogen. The nitrogen generator uses pressure swing adsorption technology. Its core material molecular sieve absorbs oxygen to produce nitrogen when passing through compressed air, and releases the adsorbed oxygen when venting under reduced pressure to realize repeated nitrogen production.
Product Advantages:
●The equipment has low operation cost, stable and reliable nitrogen purity and flow.
●The process is short, the technology is advanced and reliable, and the purity of nitrogen can be as high as 99.999%
●The device has high degree of automation, automatic fault diagnosis, convenient start and stop and full-automatic control.
●Siemens PLC control system is stable and reliable with high degree of automation.
Application fields:
Nitrogen, commonly referred to as inert gas, is used in some inert atmospheres for metal treatment and in bulbs to prevent arcing, but it is not chemically inert. It is an essential element in animal and plant life and an integral part of many useful compounds. Nitrogen combines with many metals to form hard nitrides, which can be used as wear-resistant metals.
A small amount of nitrogen in steel will inhibit grain growth at high temperature and improve the strength of some steels. It can also be used to produce a hard surface on steel. Nitrogen can be used to produce ammonia, nitric acid, nitrate, cyanide, etc; In the manufacture of explosives; Filled high temperature thermometer, incandescent bulb; Form inert material to preserve the material and use it in a drying oven or glove bag. Liquid nitrogen during food freezing; As a coolant in the laboratory.
Technical parameters:
● Nitrogen delivery ≤500Nm3/hr;
● Purity 99.999%
● Pressure 0.5~0.8 Mpa
● Atmospheric dew point ≤－40℃
Product picture:
