Product Details:
|
| Material: | Steel | Color: | Bright Or Customized |
|---|---|---|---|
| Oxygen Output: | ≤75Nm3/hr | Purity: | 93%±3 |
| Pressure: | 0.4~1.0Mpa | Atmospheric Dew Point: | ≤－40℃ |
| High Light: | Alu Soldering PSA Oxygen Generator,No Leakage PSA Oxygen Generator,75 Nm3/hr Oxygen Making Machine |
||
Fast Opening And Closing Speed , No Leakage And Long Service Life Of PSA Oxygen Generator
| Product name |
PSA Oxygen Generator |
| Oxygen delivery |
≤75Nm3/hr |
| Purity |
93%±3 |
| Pressure |
0.4~1.0 Mpa |
| Atmospheric dew point |
≤－40℃ |
Working Principle Description:
The compressed air is removed from oil, dust and other solid impurities and most of the gaseous water by the air pretreatment system, and enters the oxygen and nitrogen separation unit equipped with zeolite molecular sieve (ZMS). The nitrogen, carbon dioxide and water vapor in the air are selectively adsorbed by the adsorbent, and the oxygen is enriched through the oxygen and nitrogen separation unit as the product gas. When the adsorbent in the oxygen nitrogen separation unit is close to adsorption saturation, the compressed air enters another regenerated adsorption tower to continue to adsorb and produce oxygen. The saturated adsorption tower discharges the pressure to the atmospheric pressure and introduces some product oxygen to clean the adsorbent bed, so as to desorb and regenerate the saturated adsorbent, so as to prepare for the next adsorption.
Product Advantages:
● The new pneumatic stop valve has fast opening and closing speed, no leakage and long service life, which can meet the frequent use of PSA process and has high reliability;
● Fast opening and closing speed make sure that the oxygen will be produced in a short time;
● No leakage and long service life ensure that purity of oxygen and can work for a long time;
● The adsorption performance of zeolite molecular sieve is kept in a pressing state, so as to ensure that there is no fluidization phenomenon in the adsorption process and effectively prolong the service life of zeolite molecular sieve;
● The performance of the equipment is stable, and PLC control is adopted to realize full-automatic operation with low annual failure rate.
Application fields:
PSA oxygen generators are widely used in different areas, including medical, plateau, environmental protection, combustion-supporting, cultivation, laboratory, chemical industry, electron, medicine, food, marine, aluminium soldering, lithium cell, heat treatment, laser cutting and etc.
Technical parameters:
● Oxygen delivery ≤75Nm3/hr;
● Purity 93%±3
● Pressure 0.4~1.0 Mpa
● Atmospheric dew point ≤－40℃
Product picture:
