12Nm3/Hr 0.6Mpa Oxygen Manufacturing Machine For Medical Industry

Easily Start And Stop Of Oxygen Making Machine To Produce Gas Steadily

Working Principle Description:

Under a certain pressure, the diffusion rate of nitrogen and oxygen in zeolite molecular sieve is quite different. In a short period of time, nitrogen molecules are adsorbed by zeolite molecular sieves, and oxygen molecules are enriched in the gas phase to achieve the separation of oxygen and nitrogen.

The nitrogen adsorption capacity of zeolite molecular sieve is obviously different with the pressure. Reducing the pressure can desorb the nitrogen molecule adsorbed by zeolite molecular sieve, so that the zeolite molecular sieve can be regenerated and reused.

The process of two adsorption towers is adopted. One tower produces oxygen by adsorption, the other by desorption and regeneration, and circulates alternately to continuously produce high-quality oxygen.

Product Advantages:

· wide applicable gas source, high purity, simple process, operation automation, low operation cost, etc

· Fully automatic operation of the equipment, the whole process can be realized unattended;

· The system is convenient, fast and cheap on-site oxygen production. The raw material comes from the natural air, which is the low-cost oxygen supply mode.

Application fields:

PSA oxygen generators are widely used in different areas, including medical, plateau, environmental protection, combustion-supporting, cultivation, laboratory, chemical industry, electron, medicine, food, marine, aluminium soldering, lithium cell, heat treatment, laser cutting and etc.

Technical parameters:

● Oxygen delivery ≤12Nm3/hr;

● Purity 93%±3

● Pressure 0.4~1.0 Mpa

● Atmospheric dew point ≤－40℃

Product picture:
