48Nm3/Hr 1.0Mpa PSA Oxygen Generator Working Continuously

48Nm3/Hr 1.0Mpa PSA Oxygen Generator Working Continuously
48Nm3/Hr 1.0Mpa PSA Oxygen Generator Working Continuously

Large Image :  48Nm3/Hr 1.0Mpa PSA Oxygen Generator Working Continuously

Product Details:
Place of Origin: China
Brand Name: Cherish
Model Number: PO-48-93
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: Plywood box
Delivery Time: Within 3 month after receiving deposit.
Payment Terms: T/T
Supply Ability: 60 set/ month

48Nm3/Hr 1.0Mpa PSA Oxygen Generator Working Continuously

Description
Material: Cherish Color: Bright Or Customized
Oxygen Output: ≤48Nm3/hr Purity: 93%±3
Pressure: 0.4~1.0Mpa Atmospheric Dew Point: ≤-40℃
Highlight:

48Nm3/Hr PSA Oxygen Generator

,

1.0Mpa PSA Oxygen Generator

48Nm3/Hr 1.0Mpa PSA Oxygen Generator Working Continuously



1. Working principle of industrial oxygen generator:

Pressure swing adsorption (PSA) method is a new oxygen technology developed rapidly in 1970s. It is the air as raw material, using a highly efficient, highly selective solid adsorbent - molecular sieve to nitrogen and oxygen selective adsorption, the air nitrogen and oxygen separation. Both nitrogen and oxygen have quadrupole moment, so the adsorption capacity of nitrogen in zeolite molecular sieve is stronger than oxygen (the interaction between nitrogen and ions on molecular sieve surface is stronger). Therefore, when air passes through the adsorption bed equipped with zeolite molecular sieve adsorbent under pressure, nitrogen is absorbed by the molecular sieve. Due to less adsorption of oxygen, it is enriched in the gas phase and flows out of the adsorption bed, so that oxygen and nitrogen are separated to obtain oxygen. When the molecular sieve adsorbs nitrogen to near saturation, stop the air and reduce the pressure of the adsorption bed, the nitrogen adsorbed by the molecular sieve can be desorbed, and the molecular sieve is regenerated and reused. Oxygen can be produced continuously by switching between two or more adsorption beds. The boiling points of argon and oxygen are close to each other. Therefore, pressure converter adsorption oxygen plant can only obtain oxygen with a concentration of 90%~95% (the limit concentration of oxygen is 95.6%, and the rest is argon), which is also called oxygen enrichment when compared with the concentration of 99.5% or more in cryogenic air separation plant. The whole system consists of the following components: compressed air purification module, air storage tank, oxygen and nitrogen separation device, oxygen buffer tank.



2. Technical features of PSA industrial oxygen generator:

  • The compressed air is equipped with air purification and drying treatment device, which can prolong the service life of molecular sieve;
  • The new pneumatic globe valve has the advantages of fast opening and closing speed, no leakage, long switching life, frequently use of PSA process and high reliability;
  • Perfect process design, selection of new molecular sieve;
  • Adopt the new oxygen production process, continuously optimize the device design, reduce energy consumption and capital investment;
  • Simple process, compact equipment structure design, saving floor space;
  • Stable equipment performance, PLC control, can achieve automatic operation, low annual operation failure rate;
  • High degree of automation, fast gas production.Start, shut down just press the button, start within 20 minutes to produce gas;
  • Low energy consumption, low operating costs, raw air from nature, only offering compressed air and power can produce oxygen;
  • Automated operation of the equipment, the whole process can achieve unattendent;
  • High efficiency molecular sieve loading, more compact, more solid, longer service life;
  • Pressure, purity, adjustable flow rate to meet different needs of customers;
  • Reasonable structure, advanced process, safe and stable;



Application fields:



Oxygen-enriched combustion, industrial oxygen generator can be widely used in petrochemical industry, electric, furnace, steel making, paper making, glass production, making ozone, aquaculture, sewage treatment, aerospace and other industries and fields, for the different requirements of different users of different industries use of oxygen, since provide personalized, specialized oxygen equipment, fully meet the requirements of different users of gas.



PSA industrial oxygen generator system flow

  • Obtain compressed air and its pretreatment: compressed air with a pressure of about 0.6-0.7mpa is provided by an applicable air compressor.The compressed air is removed by the p-level filter with large particle dust, cooled by the cooling dryer, and roughly dehydrated. The m-level filter removes solid-liquid mixed particles with particle size ≥1um, the h-level filter removes solid-liquid mixed particles with particle size ≥0.01um, and the c-level filter removes oil and water;
  • Fine dewatering: twin tower drying, adsorption and analysis alternately, depth dewatering, atmospheric dewpoint can be about -40℃ dry air;
  • Steady flow and steady pressure: the pure compressed air passes through the air buffer tank to provide stable pressure and flow of raw gas for the adsorption column;
  • Nitrogen removal by adsorption: compressed air enters the adsorption tower, one tower adsorption, the other tower desorption (regeneration), with two towers in parallel, alternating compression adsorption and decompression regeneration, so as to obtain continuous oxygen flow;
  • Stable flow and pressure regulation: after adsorption, the process buffer tank is set up, which meets the process requirements and plays the role of stable flow and pressure regulation, so as to obtain the stable oxygen flow with purity ≥90% and pressure ≥ 0.4mpa;
  • Device Ⅰ, Ⅱ adsorption oxygen intake valve and outlet valve of the tower and upper and lower valve automatically by programmable controller according to the stipulated time, periodically to produce gas adsorption and stripping of regeneration. A ball valve is installed in the oxygen outlet pipeline to regulate the outlet flow and oxygen purity of the oxygen generator, and a flowmeter is installed to detect the flow, and an oxygen sampling port is set up to detect oxygen purity and dew point.



Technical characteristics of pure oxygen outlet:

Production:48 Nm3/h

Purity:90%--93%

Pressure:0.4—1.0Mpa

Atmospheric dew point:--40℃(under normal pressure)

Temperature: normal temperature



Product Picture:

48Nm3/Hr 1.0Mpa PSA Oxygen Generator Working Continuously 0
